Section 2:  Frame Moulding Cutting & Joining Equipment



NFE-136    Cassese CS 4008 XL Underpinner

The CS 4008 XL Programmable Memory Underpinner The CS4008 XL is the Cassese machine for the 21st century. Fast performance and heavy duty design for high production, programmable memory with touch-screen interface for ease of use, and of course, Cassese quality corners! Touchscreen tells operator which wedge size and accessories to use. Stores up to 3000 profiles in memory. Unlimited profiles if full parameter barcode and scanner used. Thanks to its memory, the 4008XL makes it easy to change from a small photo frame to a large moulding within a few seconds. Very fast! Up to 3360 corners per hour (2 positions per corner).

Simple, user friendly programming

Fast setup time

High production capacity

Wide joining capacity : 190mm stroke (7 1/2″)

Ultra Powerful Double-action “push and tighten” rebate clamp

New retractable Ultra Clamp system retracts into the table leaving a flat surface – Great for big frames!

Built-in extension arms for large frames

Built-in networking and barcode set-up abilities

9 programmable wedge positions

Patented adjustable fences

New magnetic XL adjustable top clamp

No tools required to change wedge’s sizes

No pressure adjustment required

Cartridge loading activated by pneumatic cylinder

2-stage pneumatic clamping pedal

Wedge sensor

Safe. Will not fire wedges without moulding in position

Easy access to electrical and pneumatic parts

Stainless working table

Multi-Lingual

Special Kit to work at 45° (Optional)

Technical Data:

Mouldings:

Width: 1/8″ – 6″ (3mm to 150mm)

Height: 1/4″ – 4 3/8″ (5mm to 112mm)

Net Weight: 135 kg (300 lbs)

Smallest Internal Frame Size: 3 5/16″ x 3 5/16″ (85mm x 85mm)

Minimum Frame Dimensions: 3 5/16” x 3 5/16” (85mm x 85mm)

Stroke Length: 190mm (7 1/2″)

Wedge Sizes: 5, 7, 10, 12 & 15mm in disposable cartridges containing 275 pieces – in normal or hardwood

Power Supply: Electric: 110 v
Pneumatic: Compressed air at 100 lbs psi (compressor not included)

$ Call for Pricing

This item is shipped by freight company. Shipping is not the $6.50 default on the order page. Please call for a shipping quote.

ASC/CSE-3-24-15

Call to see if there is any pricing specials for the month.
